Sample Hold Module

The Sample Hold Module, when triggered by a input signal on one port, then capture the instantaneous signal value on its other port and relay that value to the output port until triggered again. When transitioning between held values, the module provides a smoothing function to prevent sudden discontinuities in output

For a key to understanding the following tables, see the Module Types page.

Adding Input Ports

Adding input ports is not enabled for this module.

Static Parameters

None.

Input Ports

#	Title	Description	Input Scalar Used	Parameter Scalar Used
0	Capture Signal	Instantaneous values will be captured from the signal routed to this port when a trigger value is received on Port 1.	NO	NO
1	Hold Trigger	Trigger Signal. When input on this port rises above value 0.5, A trigger state is activated and the Capture Signal will be sampled for a value to be held and routed to output.	NO	NO

Output Ports

#	Title	Description
0	Hold Value	The sampled signal value, which changes only as fast as the module is triggered.
